| Technical data | |
| Working temperature [°C] | -20.....+120 |
| Storage temperature [°C] | 6......+20 |
| Medium pressure [bar] | 0......4 |
| Pressure diference [bar] | 2.5......3 |
| Optimum control pressure | Medium pressure+Pressure diference |
| Compressed air to | ISO 8573-1:2010 |
| Painting | Powder coated 60-80 m |
| Material | |
| Housing | Cast aluminum alloy, cast stainless steel |
| Housing cover | Cast aluminum alloy,cast stainless steel |
| Seal or sleeve | Anti abrasive natural rubber,EPDM,others |
| Bolts&Nuts | Carbon steel |
| DN | φD | φDF | n | φd | φD1 | L | C | E | GW | Volume | PS |
| (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (inch) | (mm) | (kg) | (L**) | Max (bar) | |
| 40 | 150 | 88 | 4 | 18 | 110 | 155 | G 1/4'' | 26 | 3.2 | 0.20 | 6 |
| 50 | 165 | 102 | 4 | 18 | 125 | 183 | G 1/4'' | 30 | 3.7 | 0.30 | 6 |
| 65 | 185 | 122 | 4 | 18 | 145 | 183 | G 1/4'' | 28 | 4.3 | 0.45 | 6 |
| 80 | 200 | 138 | 8 | 18 | 160 | 228 | G 1/4'' | 31 | 5.6 | 0.95 | 6 |
| 100 | 220 | 158 | 8 | 18 | 180 | 280 | G 1/4'' | 35 | 8.4 | 1.70 | 6 |
| 125 | 250 | 184 | 8 | 18 | 210 | 348 | G 1/4'' | 40 | 12.0 | 3.50 | 6 |
| 150 | 285 | 212 | 8 | 22 | 240 | 418 | G 1/4'' | 43 | 17.0 | 7.00 | 6 |
| 200 | 340 | 268 | 8 | 22 | 295 | 558 | G 3/8'' | 60 | 35.0 | 15.50 | 4 |
PS: max control pressure
| Advantage | |
* Compact design * Free passage * No plugging * 100% shut off * Easy maintenance * Anti-abrasive * Quick open-close |
| Application | |
For Pneumatic conveying system * Powder industry: granual, epoxy painting, glass,plastic * Chemical industry: acid,fuel,liquid,fertilizer * Food industry: syrup, ice cream, milk,liquid food * Others: cable, dust, salt, water,slurry,waste,sludege |
