Series BMPS3

Features Design ：3 way pneumatically actuated pinch valve
Sealing principle： Eleastic lip seal
Mounting position ：Any
Type of mounting : In-line installation
Direction of flow : unidirectional
Valve function : 2/2 way,normally open
Reset method : Rebound resilience
Nominal pressure : PN10
Sleeve feature : Replaceable
Connection : G,BSP,NPT female thread
Contact
  • Product Description
  • Download
Technical data
Working temperature [°C]-20 .....+120
Storage temperature [°C]6...... +20
Medium pressure [bar]0.......6
Pressure diference [bar]2......3
Opimum control pressure[bar]
Medim pressure+Pressure difference
Compress air to
ISO 8573-1:2010


Material
HeadPVC
HousingPOM
SocketPOM
Seal or sleeveAnti-abrasive natural rubber
BoltsSS304
Sealing ringsilicon rubber

3 way pinch valve drawing

Dimensions
DNDiGLDD1
CTPWeight
(mm)(mm)(Inch)(mm)(mm)(mm)(mm)(mm)KG
40401 1/2''2349250G 1/4''100621.8
50502''26011663G 1/4''116802.2


Advantage

* 3 way design                      * Free passage                                         * No plugging

* 100% shut off                     * Easy maintenance                                * Anti-abrasive

        * Food grade                         * Avoid connection loose                       * Quick open-close


Application

For liquid pig feeding

*Medium: syrup,ice cream,milk, beer, liquid feeding


  • Series BMPS3 PDF
